| 2.13MP Sony IMX307 MIPI Interface M12 Fixed Focus Camera Module |
| Model No. YDS-MFC1-IMX307 V1.0 |
| Camera Module No. |
YDS-MFC1-IMX307 V1.0 |
| Resolution |
2.13MP |
| Image Sensor |
IMX307 |
| Sensor Type |
1/2.8" |
| Pixel Size |
2.9 um x 2.9 um |
| EFL |
2.80 mm |
| F.NO |
1.80 |
| Pixel |
1920 x 1080 |
| View Angle |
150.0°(DFOV) 120.0°(HFOV) 65.0°(VFOV) |
| Lens Dimensions |
14.70 x 14.70 x 21.09 mm |
| Module Size |
29.35 x 22.00 mm |
| Module Type |
Fixed Focus |
| Interface |
MIPI |
| Auto Focus VCM Driver IC |
None |
| Lens Type |
650nm IR Cut |
| Operating Temperature |
-30°C to +85°C |
| Mating Connector |
AXE530124 |
|
