| 2MP M12 Fixed Focus USB 2.0 Camera Module |
| Model No. YDS-USB-A116-60S-ZC1.2 V1 |
| Camera Module No. |
YDS-USB-A116-60S-ZC1.2 V1 |
| Image Sensor |
2MP |
| Sensor Type |
1/2.9" |
| EFL |
2.87 mm |
| F.NO |
2.2 |
| Pixel |
1600 x 1200 |
| View Angle |
92.0°(DFOV) 77.4°(HFOV) 66.4°(VFOV) |
| Lens Dimensions |
13.10 x 13.10 x 16.10 mm |
| Module Type |
Fixed Focus |
| Interface |
USB 2.0 |
| Output Format |
MJPG |
| Auto Control |
Saturation, Contrast, Acutance
White Balance, Exposure |
| Audio (Optional) |
Digital Microphone, Single, Dual Channel |
| Input Voltage |
DC 5V |
| Working Current |
Max 300mA |
| Size |
32.00 x 32.00 x 17.70 mm |
| System Compatibility |
Windows XP (SP2, SP3), Vista, 7, 8, 10, 11
Android, Mac OS, Linux or OS with UVC UAC Driver, Raspberry Pi by USB Port |
| Software for USB Camera |
AMCAP, Webcam Viewer, V4L2 Controls
Contacam, VLC Player, MotionEye OS
iSpy, ZoneMider, Yawcam |
| Lens Type |
650nm IR Cut |
| USB Cable |
USB Cable |
|
